PEX Anti UV yeeb nkab
PE-XA Anti UV yeeb nkab yog 3- txheej PE-Xa yeeb nkab. Cov qauv yog PE-Xa yeeb nkab li txheej txheej, anti uv txheej raws li nruab nrab txheej, thiab xim txheej raws li txheej txheej. Peb tuaj yeem ua rau lawv txawv xim raws li cov neeg siv khoom xav tau.
Hauj lwm lawm
PE-Xa Anti UV yeeb nkab yog 3- txheej PE-Xa yeeb nkab. Cov qauv yog PE-Xa yeeb nkab li txheej txheej, anti uv txheej raws li nruab nrab txheej, thiab xim txheej raws li txheej txheej. Peb tuaj yeem ua rau lawv txawv xim raws li cov neeg siv khoom xav tau. Cov kav dej PE-Xa no tsim nyog rau cov dej haus, kub thiab txias, rov ua dua tshiab, los nag thiab dej thiab cov kav dej.
Dimension
Cov khoom tseem ceeb: 100% Virgin LG188 / Lotte 8100GX
Cov txheej txheem ntau lawm: ISO{0}}: 2003
Pob: DN 16-32 100m / 200m / 300m ib yob
DN 16-50 3m / 4m / 6m ib qhov ntev
Yob ntev tuaj yeem kho raws li qhov xav tau.
|
CODE |
S SERIES |
SIZE |
|
TXA 201 |
S5 |
16×1.8 |
|
TXA 202 |
S5 |
20×1.9 |
|
TXA 203 |
S5 |
20×2.0 |
|
TXA 204 |
S5 |
25×2.3 |
|
TXA 205 |
S5 |
32×2.9 |
|
TXA 206 |
S4 |
16×2.0 |
|
TXA 207 |
S4 |
20×2.3 |
|
TXA 208 |
S4 |
25×2.8 |
|
TXA 209 |
S4 |
32×3.6 |
|
TXA 210 |
S3.2 |
16×2.2 |
|
TXA 211 |
S3.2 |
20×2.8 |
|
TXA 212 |
S3.2 |
25×3.5 |
|
TXA 213 |
S3.2 |
32×4.4 |
Lub cev & Tshuaj
Cov khoom
|
Yam khoom |
Kev xav tau |
Lub sijhawm kuaj |
Ntsuas kub |
Hoop Kev nyuaj siab |
|
Longitudinal Reversion |
Tsawg dua lossis sib npaug li 3 feem pua |
1h (en Tsawg dua lossis sib npaug li 8mm) |
120 degree |
___ |
|
Hydrostatic Stress Test |
Tsis muaj brusting Tsis to |
22H 165H 1000H |
95 degree 95 degree 95 degree |
4.7mpa ua 4.6 Mpa 4.4Mpa |
|
Thermal stability |
Tsis bursting Tsis to |
8760H |
110 degree |
2.5 Mpa |
|
Crosslinking Degree |
Ntau dua lossis sib npaug li 75 feem pua |
___ |
___ |
___ |
Daim ntawv thov
1 Portable dej kav dej (dej txias & dej kub)
2 Underfloor Radiate Cua sov Systems
3 Cua Txias, Ice & Snow Melting Systems
4 Cov Chaw Ua Haujlwm (Compressed air, installation of toxic fluids) thiab lwm yam.
